G Series (New Design)

G3060S-C6

FEATURES

● Integrated Intel i5-1235U/1.30GHz, 10-core 12-thread processor

● 2*SODDR4 3200MHz, up to 64GB

● 2*HDMI2.0, 1*DP1.4, 1*VGA

● 2*Intel I210AT Gigabit Ethernet ports

● 6*RS232/485 DB9 serial ports, COM1~2 support CAN (need to load CAN module)

● 4*USB3.0, 2*USB2.0

● Support DC 9~36V wide voltage

● Fanless cooling


Product description

Model

G3060S-C6   V2.0(1235U)



Chassis



Material/structure

Aluminium   alloy + sheet metal, fanless cooling

Colour

Black

Size   (LWH)

205*192*68.4MM

Weight   (bare net)

2.2KG

Installation

Desktop/Wall   Mount/DIN Rail(35mm)

Motherboard



CPU

Intel®i5-1235U/1.30GHz,   Turbo 4.4GHz, 10-core 12-thread processor, TDP 15W

Display

Intel®Iris   Xe Graphics eligible

Memory

2*SODDR4   3200MHz , supports up to 64GB

Front   Panel  Interface



Switch

1*Boot   Button, 1*Reboot Button

LED

1*Power   Indicator, 1*Hard Drive Indicator

USB

2*USB2.0

Audio

1*Line   out, 1*Mic

Phoenix   Terminal

1*4P   (1*Boot signal/1*Power indicator signal)

Rear   Panel Interface



Switch

1*CMOS   restore key

Display   Interface

2*HDMI2.0(4096*2304@60Hz),   1*DP1.4(4096*2304@60Hz), 1*VGA, support for quad display

COM

6*RS232/485   DB9 serial port; COM1~2 can support CAN (need to load CAN module)

LAN

2*Intel   I210AT Gigabit power port

USB

4*USB3...0

DIP   Switches

6 sets of   6-position dip switches, RS232/485 switching use (dip switches are located at   the bottom of the chassis)

Power   Interface

1*DC   interface or 1*2P P=5.08mm Phoenix terminal, support DC 9~36V wide voltage   power input

Storage



SATA

1*2.5-inch   hard drive bay

MSATA

1*MSATA

M.2

1*M.2/SSD,   support Key-M, 2280, NVME PCIE x4 SSD

Expansion

MINIPCIE

1*MINIPCIE,   support WiFi or 4G

Power   Supply Type

Power   Supply Type

External   Power Adapter

Input



Voltage   Input

DC 9-36V   wide voltage

Power   output

AC TO DC 60W   or above (depending on specific equipment)

Environment

Operating   temperature

-10℃~50℃

Storage   Temperature

-20℃~70℃

Relative   Humidity

5%-95%   relative humidity, non-condensing

Operating   Vibration

0.5g rms/5-500HZ/random/operating


Order information

No.

Model

CPU

Memory

Motherboard

IO Board

HDD

LAN

COM

USB2.0

USB3.0

power

1

G3060S-C6   V2.0(1135G7)

I5-1135G7/2.4G

2*SODDR4

Q112HD1

P68-HV/P68-C4/IPC505-SW/AUDIO-IO

msata+M.2(NVME)+2.5

2*I210

6

2

4

 9-36V

2

G3060S-C6   V2.0(1195G7)

I7-1195G7/2.9G

2*SODDR4

Q112HD1

P68-HV/P68-C4/IPC505-SW/AUDIO-IO

msata+M.2(NVME)+2.5

2*I210

6

2

4

 9-36V

3

G3060S-C6   V.0(1235U)

I5-1235U/1.3G

2*SODDR4

Q122HD1

P68-HV/P68-C4/IPC505-SW/AUDIO-IO

msata+M.2(NVME)+2.5

2*I210

6

2

4

 9-36V

4

G3060S-C6   V.0(1255U)

I5-1255U/1.7G

2*SODDR4

Q122HD1

P68-HV/P68-C4/IPC505-SW/AUDIO-IO

msata+M.2(NVME)+2.5

2*I210

6

2

4

 9-36V
