| Model number | P2150S-H2 V1.0(J4125) | |
| Chassis | Material/Structure | Aluminium alloy + sheet metal material, fanless cooling |
| Colour | Iron grey + sand grain grey | |
| Dimensions (length, width and height) | L128*W126*H61.5MM | |
| Weight (bare weight) | 0.95KG | |
| Install | Desktop/Wall Mount | |
| Main board | CPU | Integrated Intel® Celeron J4125/2.00GHz Quad-Core Quad-Thread Processor, TDP 10W |
| Display | Integrated Intel® UHD Graphics 600 | |
| RAM | 1*SODDR4 2400MHz, supports up to 8GB | |
| Front panel interface | Power | 1*Power Switch, 1*One-Key Restore, 1*ACLOSS (Power On and Off DIP Switch) |
| LED | 1*Hard Drive Indicator, 1*Power Indicator | |
| USB | 2*USB3.0, 2*USB2.0 | |
| SIM | 1*SIM standard card slot | |
| Rear panel interface | Display Interface | 1*HDMI1.4(4096*2160@30Hz), 1*HDMI2.0(4096*2160@60Hz) |
| AUDIO | 1*Line out, 1*Mic | |
| COM | 2*RS232/485 DB9 serial port, support the 9th pin with power function | |
| LAN | 2*RTL8111H, support Wake on LAN, PXE | |
| USB | 2*USB3.0, 2*USB2.0 | |
| Power supply | 1*DC 12V(5.5*2.5) | |
| Store | SATA | 1*2.5 inch HDD bay |
| M.2 | 1*M.2/SSD, support Key-M, 2280, SATA standard SSD | |
| Extend | MINIPCIE | 1*MINIPCIE, support 4G module |
| M.2 | 1*M.2/WiFi, support Key-E, 2230, WIFI module | |
| Power supply type input | Power supply type | External power adapter |
| Voltage input | DC 12V | |
| Power output | AC TO DC 36W or above | |
| Environment | Operating temperature | -10℃～50℃ |
| Storage temperature | -20℃～70℃ | |
| Relative humidity | 5%-95% relative humidity, no condensation | |
| Working vibration | 0.5g rms/5-500HZ/random/operating | |
Order Information
| No. | Model | Processor | Motherboard | Memory | IO Board | LAN | COM | HDMI | VGA | USB2.0 | USB3.0 | Power |
| 1 | P2150S-H2 V1.0(J6412) | J6412/2.0G | STX-N641 | 1*SODDR4 | N41-HD | 2*8111H | 2 | 2 | 1 | 4 | 4 | DV 12V |
| 2 | P2150S-H2 V1.0(J4125) | J4125/2.0G | STX-N41 | 1*SODDR4 | N41-HD | 2*8111H | 2 | 2 | 1 | 4 | 4 | DV 12V |
