| Model number | G3060S-C6 V1.0(1135G7) | |
| Chassis | Material/Structure | Aluminium alloy + sheet metal material, fanless cooling |
| Colour | Iron grey + sand grain grey | |
| Dimensions | 205*192*63.5MM | |
| Weight (bare weight) | 2.2 KG | |
| Install | Desktop/embedded /DIN rail | |
| Main board | CPU | Intel®i5-1135G7/2.40GHz, Quad-Core 8-Thread Processor, TDP 15W |
| Display | Intel®Iris Xe Graphics | |
| Internal memory | 2*SODIMM DDR4 3200MHz , support up to 64GB | |
| Front panel interface | Switch | 1*Boot button, 1*One-Key Restore |
| LED | 1*Power Indicator, 1*Hard Drive Indicator | |
| USB | 2*USB2.0 | |
Phoenix terminal | 1*4P(1*Boot signal/1*Power indicator signal) | |
| Audio | 1*Line out, 1*Mic | |
| Rear panel interface | Switch | 1*CMOS restore button |
| USB | 2*USB3.0, 2*USB2.0 | |
| COM | 6*RS232/485 DB9 serial port; COM1~2 can support CAN (need to load CAN module) | |
| LAN | 2*Intel I210AT Gigabit power port | |
| Phoenix terminal | 2*8pin(7 in 7 out GPIO tape isolation) | |
| Display Interface | 1*HDMI2.0(4096*2304@60Hz), 1*HDMI1.4, 1*VGA, support for triple display | |
| Dip switches | 6 sets of 6-position dip switches, RS232/485 switching use (dip switches are located at the bottom of the chassis) | |
| Power interface | 1*DC interface or 1*2P P=5.08mm Phoenix terminal, support DC 9~36V wide voltage power input | |
| Store | SATA | 1*2.5-inch hard drive bay |
| MSATA | 1*MSATA | |
| M.2 | 1*M.2/SSD, support Key-M, 2280, NVME PCIE x4 SSD | |
| Extend | Mini PCIE | 1*MINIPCIE, support WiFi/4G module |
| Power supply type input | Power supply type | External power adaptor |
| Voltage input | DC 9-36V wide voltage | |
| Power output | AC TO DC 60W or above | |
| Environment | Operating temperature | -10℃～50℃ |
| Storage temperature | -20℃～70℃ | |
| Relative humidity | 5%-95% relative humidity, no condensation | |
| Working vibration | 0.5g rms/5-500HZ/random/operating | |
Order Information
| No. | Model | CPU | Motherboard | Memory | IO Board | LAN | COM | HDMI | VGA | USB2.0 | USB3.0 | Power |
| 1 | G3060S-C6 V1.0(7300U) | I5-7300U/2.6G | P68 | 2*SODDR4 | P68-HV/P68-C4/IPC505-SW/AUDIO-IO | 2 | 6 | 2 | 1 | 4 | 2 | 9-36V |
| 2 | G3060S-C6 V1.0(J6412) | J6412/2.0G | P642 | 2*SODDR4 | P68-HV/P68-C4/IPC505-SW/AUDIO-IO | 2 | 6 | 2 | 1 | 4 | 2 | 9-36V |
| 3 | G3060S-C6 V1.0(8260U) | I5-8260U/1.6G | P82 | 2*SODDR4 | P68-HV/P68-C4/IPC505-SW/AUDIO-IO | 2 | 6 | 2 | 1 | 4 | 2 | 9-36V |
| 4 | G3060S-C6 V1.0(10210U) | I5-10210U/1.6G | P102 | 2*SODDR4 | P68-HV/P68-C4/IPC505-SW/AUDIO-IO | 2 | 6 | 2 | 1 | 4 | 2 | 9-36V |
| 5 | G3060S-C6 V1.0(1135G7) | I5-1135G7/2.4G | P112 | 2*SODDR4 | P68-HV/P68-C4/IPC505-SW/AUDIO-IO | 2 | 6 | 2 | 1 | 4 | 2 | 9-36V |
| 6 | G3060S-C6 V1.0(1235U) | I5-1235U/1.3G | P122 | 2*SODDR4 | P68-HV/P68-C4/IPC505-SW/AUDIO-IO | 2 | 6 | 2 | 1 | 4 | 2 | 9-36V |
