| Model number | C4350Z-L4 V1.1(J4125) | |
| Chassis | Material/Structure | All aluminium alloy, fanless cooling structure |
| Colour | Black colour | |
Dimension(L*W*H) | 141.4*126*56.5MM | |
| Weight (bare net) | 0.98KG | |
| Installation | Desktop/Wall Mount | |
| Motherboard | CPU | Integrated Intel® Celeron J4125/2.00GHz Quad-Core Quad-Thread Processor,TDP 10W |
| Display | Integrated Intel® UHD Graphics 600 core graphics card | |
| RAM | 1*SODIMM slot, support single-channel 2400MHz DDR4 memory, maximum support 8GB | |
| Front Panel Connectors | POWER | 1*Power switch, 1*Reset switch, 1*ACLOSS (power on/off toggle switch) |
| LED | 1*Power Indicator, 1*Hard Drive Indicator | |
USB | 2*USB3.0, 2*USB2.0, 1*USB2.0 built-in | |
| SIM | 1*SIM card slot | |
Rear Panel Interface | Phoenix Terminal | 1*6pin Phoenix terminal (including 2 in 2 out GPIO/ VCC/ GND) |
| LAN | 4*Intel I225 2.5G Gigabit LAN card, support Wake on LAN/PXE function | |
| COM | 2*RS232 DB9 serial port, COM2 support RS485 | |
| Power supply | 1*DC12V power supply interface | |
| Storage | SATA | 1*2.5-inch hard drive bay |
| MSATA | 1*MSATA, transfer rate up to 6Gbps | |
| Expansion | Mini PCIE | 1*Mini-PCIE, support 4G module |
| M.2 | 1* M.2/WiFi,support Key-E, 2230, WIFI module | |
| OS support | Microsoft Windows | Windows 10 |
| Linux | Ubuntu | |
| Watch Dog | Support hardware reset function (L256，0~255 seconds) | |
| Power Supply | Power Type | External power adaptor |
| Voltage Input | DC 12V | |
| Power output | AC TO DC, 60W | |
| Environment | Operating temperature | -10℃～50℃ |
| Storage temperature | -20℃～70℃ | |
| Relative humidity | 5%-95% relative humidity, no condensation | |
| Working vibration | 0.5g rms/5-500HZ/random/operating | |
Order Information
| No. | Model | Processor | Motherboard | Memory | IO Board | GPIO | LAN | COM | HDMI | USB 2.0 | USB 3.0 | Power |
| 1 | C4350Z-L4 V1.1(J4125) | J4125/2.0GHz | R41V | 1*SODDR4 | R36F-C2 | 2in2out | 4 | 2 | 1 | 2 | 2 | DC 12V |
